| Recommended Daily Volume |
i3200/i3250 ADF: Up to 15,000 pages per day
i3400/i3450 ADF: Up to 20,000 pages per day
i3250/i3450 integrated A4 size flatbed: 100 pages per day |
Throughput Speeds
(landscape, letter/A4 size, black and white, grayscale, color) |
i3200, i3250 ADF: Up to 50 ppm/100 ipm at 200 dpi and 300 dpi
i3400, i3450 ADF: Up to 90 ppm/180 ipm at 200 dpi and 300 dpi (up to 80 ppm/160 ipm in color)*
(Throughput speeds may vary depending on your choice of driver, application software, operating system and PC.)
*Now even faster! |
| Scanning Technology |
Dual CCD;
Grayscale output bit depth is 256 levels (8-bit); color capture bit depth is 48 bits (16 x 3); color output bit depth is 24 bits (8 x 3) |
| Illumination |
Dual LED |
| Operator Control Panel |
Graphical LCD display with four operator control buttons |
| Optical Resolution |
600 dpi |
| Output resolution |
100 / 150 / 200 / 240 / 300 / 400 / 500 / 600 / 1200 dpi |
| Max. / Min. Document Width |
Auto-feed: 305 mm (12 in.) / 63.5 mm (2.5 in.)
Hand-feed: 305 mm (12 in.) / 50 mm (2 in.) |
| Max. / Min. Document Length |
Auto-feed: 863.6 mm (34 in.) / 63.5 mm (2.5 in.)
Hand-feed: 863.6 mm (34 in.) / 50 mm (2 in.) (rear exit only)
Long document mode: 4.1 meters (160 in.) maximum length
(The scanners support continuous scanning mode) |
| Paper Thickness and Weight |
34-413 g/m2 (9-110 lb.) paper |
| Feeder/Elevator |
Up to 250 sheets of 80 g/m2 (20 lb.) paper |
| Paper Path Options |
Documents can exit into the front output tray, or at the rear of the scanner if the straight-through paper path option is manually selected |
| Document Sensing |
Ultrasonic multi-feed detection; Intelligent Document Protection |
| Connectivity |
USB 2.0; USB 3.0 Compatible |
| Software Support |
Fully supported by KODAK Capture Pro Software and KODAK Asset Management Software
WINDOWS Bundled software: TWAIN, ISIS, and WIA drivers; KODAK Capture Pro Software Limited Edition; Smart Touch (LINUX SANE and TWAIN drivers available from www.kodakalaris.com/go/scanonlinux); KOFAX certified
MAC Bundled software: NEWSOFT PRESTO! PAGEMANAGER; TWAIN driver (available web download only) |
| Imaging Features |
Perfect Page Scanning; iThresholding; adaptive threshold processing; deskew; autocrop; relative cropping; aggressive cropping; electronic color dropout; dual stream scanning; interactive color, brightness and contrast adjustment; automatic orientation; automatic color detection; intelligent background color smoothing; intelligent image edge fill; image merge; content-based blank page detection; streak filtering; image hole fill; sharpness filter; auto brightness, special document mode; continuous scanning mode; toggle patch; auto photo cropping; segmented bitonal images |
| File Format Outputs |
Single and multi-page TIFF, JPEG, RTF, BMP, PDF, searchable PDF |
| Warranty (US and Canada) |
90 days (Advanced Unit Replacement) |
| Accessories (Optional) |
KODAK Legal Size Flatbed Accessory; KODAK A3 Size Flatbed Accessory; document imprinting accessory (rear-side, post-scan imprinting of up to 40 alphanumeric characters, with 11 imprinting positions) |
| Electrical Requirements |
100-240 V (International); 50-60 Hz |
| Power Consumption |
Off mode: <0.5 watts; Running: <75 watts; Sleep mode: <4.5 watts |
| Environmental Factors |
| EPEAT Registered |
 |
| ENERGY STAR Qualified |
|
| Operating Temperature: 15-35° C (59-95° F) |
|
| Operating Humidity: 15% to 80% RH |
| |
Acoustical Noise
(operator position sound pressure level) |
Off or Ready mode: <30 dB(A)
Operating mode: <60 dB(A) |
| Recommended PC Configuration |
INTEL CORE i7 processor, 3.4 GHz or higher, 4 GB RAM or more (WINDOWS and LINUX)
INTEL CORE i7 processor, 2.0GHz quad-core, 4 GB of RAM, USB 2.0 (MAC) |
| Supported Operating Systems |
WINDOWS XP SP3 (32-bit and 64-bit), WINDOWS VISTA SP2 (32-bit and 64-bit), WINDOWS 7 SP1 (32-bit and 64-bit), WINDOWS 8 (32-bit and 64-bit), WINDOWS 8.1 (32-bit and 64-bit), UBUNTU 14.04 (LTS)* (32-bit and 64-bit), MAC OS v.10.7, 10.8, 10.9* |
| Approvals and Product Certifications |
AS/NZS CISPR 22:2009 + A1:2010 Class B (C-Tick Mark), CAN/CSA-C22.2 No. 60950-1-07 (C-UL Mark), Canada ICES-003 Issue 5 (Class B), GB4943.1:2011, GB9254:2008 (Class B), GB 17625.1:2003 Harmonics (CCC "S&E" Mark), EN 55022:2010 ITE Emissions (Class B), EN 61000-3-3 Flicker, EN 55024:2010 ITE Immunity (CE Mark), EN 60950-1:2006 + A11, A12, A1 (TUV GS Mark), IEC 60950-1, CISPR 22:2008 (Class B), VCCI V3/2012.04 (Class B), CNS 13438:2006 (Class B), CNS 14336-1 (BSMI Mark), UL 60950-1:07 (UL Mark), CFR 47 Part 15 Subpart B (FCC Class B), Argentina S-Mark |
| Consumables Available |
Roller cleaning pads, STATICIDE Wipes, consumables kit (includes feed module, separation module, separation pad, front transport rollers) |
| Dimensions |
i3200 / i3400: Height: 9.4 in. / 23.8 cm Width: 17 in. / 43.18 cm Depth (with input tray closed): 14.6 in. / 37.1 cm Weight: 35 lbs / 15.8 kg
i3250 / i3450: Height: 10.2 in. / 25.7 cm Width: 17 in. / 43.18 cm Depth (with input tray closed): 14.6 in. / 37.1 cm Weight: 39 lbs / 17.7 kg |
| *The Smart Touch application is not supported on these operating systems. |
